Lighting cameraman

My favourite lighting equipment is made by Dedolight, who are legendary in the film & TV industry.

I have an extensive range of Dedolight equipment, from the little 40W DLED3 fixtures, all the way up to the big 1.2KW HMI and 5-foot Panaura softlight. I take great pride in using these amazing lights.

Lighting Kit

LED RGBACL		LED OPEN-FACE
2 x Dedo DLED7, NEO Color		1 x Orion 300 FS
1 x Orion 300 FS, open-face		2 x Zhiyun Molus G200 300W, Bi-Colour
		1 x Zhiyun Molus G60 60W, Bi-Colour
LED FOCUSABLE
1 x Dedo DLED10, Daylight		HMI FOCUSABLE
6 x Dedo DLED7 Turbo, Bi-colour		1 x Dedo 1.2KW
5 x Dedo DLED3 Turbo, Bi-colour		1 x Dedo 400W
3 x Dedo Ledzilla, Bi-colour		2 x Dedo 200W

LED PANELS		HMI LARGE SURFACE SOFT LIGHTS
2 x Dedo Turbo Felloni 12 x 12-inch, Bi-colour		1 x Dedo PanAura 5-foot, 400W
2 x Dedo Felloni 12 x 12-inch, Bi-colour		1 x Dedo PanAura 3-foot, 200W
2 x Dedo Liteflex 12 x 12-inch flexible, waterproof, Bi-colour		1 x Dedo Soft 400W in 3-foot Chimera Lantern
		1 x Dedo Soft 200W in 3-foot Chimera Lantern
COLOUR & EFFECTS LIGHTS
2 x Dedo DLED7, NEO Colour		KINO FLO
1 x Orion 300 FS		1 x 2ft Select 20 LED RGB soft light
1 x Kino Flo Select 20 with gel pre-sets & effects		2 x 4ft 4Bank daylight soft lights
2 x Ledgo AltaTube 120, 4-foot with gel pre-sets & effects		1 x Kino Flo Kamio 6 on-camera ring light
2 x Ledgo AltaTube 80, 2-foot with gel pre-sets & effects
1 x Luxli Cello with with gel pre-sets & effects		TUNGSTEN
1 x Chauvet Slim PAR PRO tri		1 x Dedo DLH650, Focusable
1 x Dedo DLED4-UV (Ultraviolet) 400nm wavelength		2 x Dedo DLH4, Focusable
		2 x Dedo DLHM4-300, Focusable
DEDO IMAGER PROJECTION ATTACHEMENTS		1 x Dedo DLH1000S, Dedicated soft light
5 x DP1.2 imager for DLED7 & 200 series fixtures		2 x Dedo DLH1 X300, Dedicated soft light
5 x DP2.1 with built-in shutters for DLED7 & 200 series
1 x DP3 Slide projector, for DLED7 & 200 series		DIFFUSION & MODIFIERS
1 x DP4 imager for series 400		1 x Lastolite 4-meter Panoramic Background with Granite texture.
1 x DP1s imager for DLED3		2 x Butterfly/overhead frames 2x2m, 1x1m
		2 x Honeycomb grids for Dedo Turbo Felloni
DMX CONTROLLED LIGHTS		2 x Soft boxes for Turbo Felloni, 60x60 cm
1 x Orion 300 FS		3 x Soft boxes for Dedo DLED7, 30 x 30 cm
2 x Dedo DLED7, NEO Color, focusable		2 x Grids for Dedo PanAura, 5 & 3-foot
1 x Dedo DLED10, Daylight, focusable		2 x Aputure Light Dome Mini III with grids
2 x Dedo DLED7, Bi-colour, focusable
2 x Dedo DLHM4-300, Tungsten, focusable		ATMOSPHERIC EFFECTS
2 x Dedo Turbo Felloni, Bi-colour, 12x12-inch, soft		1 x Chauvet Fog/Smoke machine
2 x Ledgo AltaTube 120, RGB, 4-foot, soft
2 x Ledgo AltaTube 80, RGB, 2-foot, soft
1 x Kino Flo Diva-Lite Select 20, RGB, 2-foot, soft
1 x Chauvet Slim PAR PRO tri, RGB, wash light

Dedolight Lightstream Reflected Light System

LIGHTSTREAM REFLECTORS		LED - PARALLEL BEAM LIGHT SOURCES
1 x 100x100 cm Front surface grade 1, rear grade 4		1 x Dedo DLED10 with DPBA-1419 Parallel Beam Intensifier
2 x Set 50x50 cm Grades 1,2,3,4,5		2 x Dedo DLED7 with Parallel Beam Intensifier
2 x Set 25x25 cm Grades 1,2,3,4,5		2 x Dedo DLED3 with Parallel Beam Intensifier
4 x Set 10x08 cm Grades 1,2,3,4
1 x Set 50x50 cm Eflect		HMI - PARALLEL BEAM LIGHT SOURCES
1 x Set 25x25 cm Eflect		1 x Dedo1.2kW with Parallel Beam Intensifier
1 x Set Lightstream Lite		1 x Dedo 400W with DPBA-1419 Parallel Beam Intensifier
		1 x Dedo 200W with Parallel Beam Intensifier
LIGHTSTREAM GRIPS
Reflector locks, articulating arms
Grip heads, ceiling clamps, etc.
Various stands & boom arms

LED Focusable

Dedolight LED Focusable fixtures share the same optical properties of the classic Dedolight, evenness of the beam and excellent colour rendition, which doesn't change during dimming.

These lights are flicker free and can be powered by battery or worldwide voltage from 100V to 240V. The Bi-colour versions are variable from 2,700K - 6,500K

DLED10 - Daylight (300W)
An extremely bright and compact fixture. When partnered with a parallel beam intensifier, the DLED10 becomes a powerful light source for the Lightstream system.

DLED7 TURBO - Bi-colour (90W)
A super bright and versatile fixture with the same precision as the original Dedolights.

DLED3 TURBO - Bi-colour (40W)
The DLED3 is the smallest member of the Dedolight family but it has the same output as the larger DLED4. The 3-head DLED3 micro lighting kit is a dream to work with.

DLED4 Ultraviolet (40W)
Produces a dark purple light to the eye but most of the light emitted is in the invisible ultraviolet range which makes various items glow - (400nm wavelength)

LED Panels

Designed and specified by Dedolight, these 12-inch high performance Bi-colour LED panels are quick and easy to set-up. They're dimmable and never get hot so breakdown is faster. Felloni lights have dedicated soft boxes and honeycombs.

Turbo Felloni
Turbos are 3 times brighter than the 'high output' Felloni. They are extremely powerful so perfect as a fill light in full daylight situations.

Felloni
These fixtures are perfect for general interview and location lighting. The low power consumption means I can run for several hours on one battery.

Tecpro LiteFlex
An incredibly lightweight, waterproof and flexible LED panel light. Battery or mains powered

Pocket Ledrama
Each LED of the LedRama changes their colour temperature individually, which maintains a much higher output than other light panels. Most of the others have rows of tungsten and daylight LEDs, so when you mix from daylight to tungsten, the daylight LEDs fade out as the tungsten fades in, so the full output is never achieved. Dedolight Ledrama is small and BRIGHT.

HMI Focusable

Dedolight HMI share the distinct clean beam associated with the smaller classic Dedolights. The Dedolight design team received an Oscar as a Scientific and Engineering Award for the development of their Series 400 lighting fixtures.

1.2Kw Dedolight

Balanced to sunlight, the Dedolight 1.2Kw HMI is an invaluable light source for day or night exteriors. The tungsten equivalent of this 1.2Kw HMI fixture is around 5,000 watt.

It’s flicker free electronic ballast allows high speed shooting up to 2,000 frames per second.

The 1.2Kw is a workhorse in the film & TV industry and can be powered from a standard household 13amp socket.

DLH1200D
Rainproof construction
Focus range 1:18
Flicker free and dimmable
DMX Controllable

575w Dedolight

This 575 watt HMI is balanced to sunlight. This series 400 gives more light output than anything in its class. The tungsten equivalent of this 575w HMI fixture is around 2,500 watt.

400/575W HMI - DLH400DT
Rainproof construction
Focus angle 50° - 4.5°
Focus range 1:20

650W Tungsten - DLH650
Colour temperature 3200°K
Dimmable
Focus range 1:13

200w Dedolight

The DLH200DT is a 200 watt daylight HMI version of the Classic series that we all know so well. It's very bright, compact and lightweight with the same superior clean beam performance of the larger Series.

The tungsten equivalent of this 200w HMI fixture is around 1,000 watt.

Flicker free and dimmable
Focus range 1:14

Large Surface Softlights

575w PanAura

Dedolight's PanAura5 is a large surface soft light that is nicknamed "The portable window” and is renowned for its beautiful light character.

PanAura is 5ft wide and just 40cm deep, so provides excellent space saving solutions compared to similar sized soft lights currently available. This allows the use of this big window sized soft light in confined spaces and on location. It’s perfect for commercials, drama or large sets requiring a broad soft source. I like to use it as a down soft light.

Output is double in comparison to a soft box in front of a Fresnel light, because Dedolight placed the light source in the focal point of the reflector.

Daylight
The DLH400SDT is a dedicated 575w HMI soft light head with perfectly even light distribution and a flicker free dimmable ballast.

Tungsten
The DLH1000SPLUS is a dedicated 1000W soft light head with perfectly even light distribution and dimmer.

I also have a PanAura3 which is 3-foot in diameter.

Chimera Pancake Lantern

For use with dedicated Dedolight 400W or 200W HMI soft fixtures. Low profile Chimera Pancake Lanterns are wonderful when used overhead as a central soft light for roundtable scenes/interviews. It’s also a great way to fill interior shooting spaces with soft, ambient light.

This Pancake Lantern includes an adjustable black skirt which limits the spread of the light output and adds a dramatic effect between light and shadow.

35" (89cm) square
17" (43cm) deep

LEDZilla

The Dedolight LEDZilla is a daylight LED camera light that is fully dimmable with no colour change and it’s flicker free.

Like it’s bigger brothers, the LEDZilla uses Dedolight double aspheric optics, so it's super bright. It has a built in tungsten dichroic filter, barn doors and is fully focusable from 4 to 56 degrees. The flip-up diffuser makes the beam even wider to around 70 degrees.

Power consumption is just 8W at it’s highest setting so it runs on small camera battery for hours.

The most useful addition to the Ledzilla is it’s 5-inch soft box, which delivers a beautiful soft on-camera light. It can also be stand mounted so ideal for traveling with when space is tight.

Imager Projection Attachments

Imager projection attachments fit to the front of Dedolights. They have a focusable lens and a slot into which accessories such as Gobos are placed. Precision light control what Dedo is famous for.

Gobos
Gobos are thin metal disks with patterns cut into them, which are projected onto backgrounds.

Framing Shutters
Four shutter blades are used to form geometric shapes of light.

Iris
18-leaf iris that closes down smoothly with a lever, maintaining a perfect circle of light, from full flood to tiny pinpoint of light.

Slide Projection
35mm slide projection with vertical and horizontal perspective control.

Eflect

EFLECT is an amazing organic looking background generator for interviews, product or miniature work.

Some time ago, I presented my ‘background reflector’ idea to Dedo Weigert of Dedolight fame. Working with Dedo and and his amazing team, we developed the idea into a new Dedolight product and named it EFLECT.

The EFLECT system is the textural equivalent of diffusion and works with a selection of newly conceived reflectors, which can be shaped and bent to create reflected textural effects; it has a unique almost 3D look.

EFLECT can be subtle or dramatic depending on the focus position of the light fixture. Generally a wide focus is dramatic while spot is softer. Slight manipulation of EFLECT widens or narrows the reflected beam spread. The system is optimised for use with focusing Dedolights.

Kino Flo

Select 20 LED

The Select 20 looks like the classic Diva-lite 400, but it’s Kino Flo's new LED soft light.

The Kinoflo Select 20 delivers a beautifully soft and gentle light. It’s bi-colour, warm to cool from 2700K to 6500K with consistent output. Full RGB mode gives me any colour I want. It's like having entire gel packs fitted into the light. It has 32 built in lighting effects: Lightning, Candle, Fire, Paparazzi, Police, TV, colour scroll effects, etc.

4ft 4BANK Fixture

The Kino Flo 4ft 4Banks are still a favourite tool amongst location and studio cameramen. They have similar brightness to a 1,000W soft light, but uses 1/10th the power. No colour temperature shift when dimmed, dead quiet and flicker free. I have two of these fixtures, perfect for green screen work.
